Xtracycle Swoop: Family Cargo E-Bike | Electric Longtail Cargo Bikes

Let's Outfit your Swoop

Everyday Rider Swoop Bundle

$940.00

Hooptie
MagicCarpet
BoomBox
PorterRack
PorterPack (on backorder)
Everyday BikePack

Bundle only available with purchase of a bike

Select accessories myself

Total: $0

Longtail Hooptie

$240.00

MagicCarpet

$75.00

PorterRack

$200.00

PorterPack
(on backorder)

$150.00

BoomBox

$125.00

Everyday BikePack

$150.00

Seeing is Believing

Video resources to show you what we're all about

Dig In: The Swoop

Hooptie Passenger System

Shimano Electric Drive

How Will my Bike Ship?

The Xtracycle Experience

Ebike Escape Review

Rascal Rides Review

Electric Bike Journal Review

THE NITTY GRITTY

Swoop ASM Geometry & Specs

Swoop 2021-2025 geometry

1	Head tube length	7.75"	197 mm
2	Fork length	16.5"	419 mm
3	Fork offset	2.5"	63.5 mm
4	Seat tube	17"	432 mm
5	Reach	15"	381 mm
6	Stack	26"	660 mm
7	Effective top tube	22.5"	572 mm
8	Actual top tube	25.5"	648 mm
9	Step over height	18"	457 mm
10	Chainstay length	32"	813 mm
11	Deck length	30"	762 mm
12	Deck height	23"	584 mm
13	Wheel base	56.3"	1430 mm
14	Actual length	83"	2108 mm

Swoop ASM Geometry

Head tube length	200 mm
Headtube Angle	71.5 degrees
Seat Tube Length	346 mm
Seat Tube Angle	71 degrees
Reach	378 mm
Stack	632 mm
Effective top tube	590 mm
Axle to Crown	470 mm
Wheelbase	1371 mm

Swoop Shimano EP8 (Class 1) component specs (2021-2025)

Available colors	Vista Blue (glossy) SOLD OUT
Bike weight	62.9 lbs
Max Gross Vehicle Weight	470 pounds
Frame material	4130 Chromoly steel
Fork material	4130 Chromoly steel
Handlebar	Kalloy AL078L, 31.8mm, 45mm rise, 24-degree backsweep, 640mm width
Grips	Marwi 7GP-03-L, 125mm long
Stem	Kalloy AS007N. Available lengths: 60mm (S), 90mm (M), 120mm (L)
Headset	FSA No. 18
Saddle	Xtracycle Comfort Saddle (2021)
Seat post	Kalloy SP3D1, 31.6mm. Available lengths: 300mm (S), 400mm (M), 450mm (L)
Seat clamp (collar)	Xtracycle LF-5233 34.9mm bolt-on
Kickstand	KickBack 3
Rear rack	Longtail RearRack
Brake levers	Tektro M745
Cabling	Internal
Front brake	Tektro M745, 4 piston hydraulic
Front rotor	Shimano SM-RT64, 180mm
Rear brake	Tektro M745, 4 piston hydraulic
Rear rotor	Shimano STEPS RT-EM600-M, 180mm
Front light	Herrmans H-Black Pro E 6-12V (attached to fender)
Rear light	Herrmans H-TRACE E-BIKE 6-12V (included)
Shifters	SRAM NX 11-S trigger shifter with X-ACTUATION (Model number SL-NX-1-A1)
Front derailleur	(none)
Rear derailleur	Sram NX11 X-HORIZON (Model number RD-NX-1-A1)
Crank	Shimano FC-EM600 or FSA CK-752, 170mm
Chainring	FSA 42 tooth cog
Cassette	SRAM GX PG-1130 A1, 11-speed, 11 tooth - 42 tooth
Chain	e-ONZE-111 Taya (174 Links)
E-assist	Shimano STEPS EP8
E-assist cycling computer	Shimano SC-E5003
Charger	Shimano STEPS EC-E6002 (120 V AC, 50 - 60 Hz, 2 amp)
Battery	Shimano STEPS BT-E8016, 630 wH (downtube, external), up to 60mi per charge depending on riding conditions and load
Front hub	KT QL-XC2F, 15mm, 100mm thru axle
Rear hub	KT QL-XC2R, 10mm, 135mm bolt-on
Front rim	26" Alex DM24, 36H A/V 13 gauge
Rear rim	20" Alex DM24, 36H A/V 13 gauge
Spokes	Pillar 13 gauge stainless w/PB13 14L brass nipples
Tires	Front: Schwalbe Super Moto-X HS 439, 26" x 2.4"; Rear: Schwalbe Super Moto-X HS 439, 20" x 2.4"
Tire compatibility	26" and 20" only, max width of 2.4"
Fenders	Aluminum (included)
Also includes	FreeLoader Too, U-tubes (2021)
E-assist class	Class 1
Max e-assist speed	20 mph
Specifications are subject to change without notice.

Swoop Shimano EP6 (Class 3) component specs (2021-2025)

Available colors	Vista Blue (glossy) or Black (matte)
Bike weight	62.9 lbs
Max Gross Vehicle Weight	470 pounds
Frame material	4130 Chromoly steel
Fork material	4130 Chromoly steel
Handlebar	Kalloy AL078L, 31.8mm, 45mm rise, 24-degree backsweep, 640mm width
Grips	Marwi 7GP-03-L, 125mm long
Stem	Kalloy AS007N. Available lengths: 60mm (S), 90mm (M), 120mm (L)
Headset	FSA No. 18
Saddle	Xtracycle Comfort Saddle (2021)
Seat post	Kalloy SP3D1, 31.6mm. Available lengths: 300mm (S), 400mm (M), 450mm (L)
Seat clamp (collar)	Xtracycle LF-5233 34.9mm bolt-on
Kickstand	KickBack 3
Rear rack	Longtail RearRack
Brake levers	Tektro M745
Cabling	Internal
Front brake	Tektro M745, 4 piston hydraulic
Front rotor	Shimano SM-RT64, 180mm
Rear brake	Tektro M745, 4 piston hydraulic
Rear rotor	Shimano STEPS RT-EM600-M, 180mm
Front light	Herrmans H-Black Pro E 6-12V (attached to fender)
Rear light	Herrmans H-TRACE E-BIKE 6-12V (included)
Shifters	Shimano SL-M4100-R 10-S Rapidfire Plus w/optical
Front derailleur	(none)
Rear derailleur	Shimano RD-M5120-SGS Deore 10/11-S Shadow Plus
Crank	FSA CK-752, 170mm
Chainring	FSA 42 tooth cog
Cassette	Shimano CS-M4100-10 10-S 11-42 tooth
Chain	KMC e10T Turbo 174L 10-S EPT Anti-Rust
E-assist	Shimano STEPS EP6
E-assist cycling computer	Shimano SC-EN500
Charger	Shimano STEPS EC-E6002 (120 V AC, 50 - 60 Hz, 2 amp)
Battery	Shimano STEPS BT-EN606, 630 wH (frame, external), up to 60mi per charge depending on riding conditions and load
Front hub	KT QL-XC2F, 15mm, 100mm thru axle
Rear hub	KT QL-XC2R, 10mm, 135mm bolt-on
Front rim	26" Alex DM24, 36H A/V 13 gauge
Rear rim	20" Alex DM24, 36H A/V 13 gauge
Spokes	Pillar 13 gauge stainless w/PB13 14L brass nipples
Tires	Front: Schwalbe Super Moto-X HS 439, 26" x 2.4"; Rear: Schwalbe Super Moto-X HS 439, 20" x 2.4"
Tire compatibility	26" and 20" only, max width of 2.4"
Fenders	Aluminum (included)
Also includes	FreeLoader Too, U-tubes (2021)
E-assist class	Class 3
Max e-assist speed	28 mph
Specifications are subject to change without notice.

Swoop 2021-2025 Compatibility

The Swoop is compatible with the following accessories: Longtail Hooptie, Longtail HalfHooptie, SnackBars, MagicCarpet, PorterRack, PorterPack (when a PorterRack is installed), Everyday BikePack, FreeLoader Too, U-Tubes, KickBack 3, EdgeRunner WheelSkirts, Thule Yepp 2 Maxi.

An important note about child seats:
If you intend to install a Yepp child seat on the Shimano powered Swoop, you will want to get the Yepp 2 Maxi. For a complete list of compatible and incompatible child seats, please see the article on child seats here.

The Yepp Maxi Easy Fit is not compatible with the Shimano powered Swoop.

Shipping your bike

Direct Home Delivery ($400): Get your bike delivered fully assembled, ready to ride, in our Big Box of Happiness anywhere in the continental United States. This premium assembly and delivery service comes with our 15 day, 50-mile trial and hassle-free return. Fully assembled bikes ship within 2 weeks. Delivery times vary based on location. For Canada, please see Shipping Xtracycle Bikes to Canada: What to know.

Unassembled ($200): Looking to DIY your bike build or work with your local bike shop for assembly? This option is for you. Choose “unassembled” and we will ship your bike and accessories directly to you for a flat shipping fee of $200. Unassembled bikes ship within 2 business days. Delivery times vary based on location. We recommend all bikes assembled at home be looked over by a bike shop before use to ensure proper assembly.

Local delivery ($175): If you are located in the Bay Area, we’ll get your bike fully assembled and sent directly to your home, ready to ride, for $175.

Local pick-up (free): Pick up your bike fully built in-store and get it home however you’d like.

Swoop 2021-2025 User Manual

Swoop 20mph assembly manual	Link to PDF

Swoop 28mph assembly manual	Link to PDF

Swoop assembly video	Link to video on Xtracycle YouTube channel

Shimano STEPS EP8 System - User manual	Link to PDF

Shimano STEPS EP6 System - User manual	Link to PDF

Shimano STEPS Battery and Charger - User manual	Link to PDF

Shimano STEPS SC-E5003 Cycling Computer - User manual	Link to PDF

Shimano STEPS SC-EN500 Cycling Computer - User manual	Link to PDF

Herrmans H-Black Pro (front light) - User manual	Link to PDF

Herrmans H-Trace e-bike (rear light) - User manual	Link to PDF

Warranty

Warranty	The Xtracycle warranty covers each steel made frame and fork of the bicycle or e-bike against defects in manufacturing and materials for the lifetime of the bike for the original owner for personal use. Aluminum frames and suspension forks are covered for five (5) years against defects in manufacturing and materials for the original owner for personal use. Commercial use warranty is valid for one (1) year for the original owner for commercial use only, regardless of frame/fork material. Please see the Terms and Conditions page for our full Warranty Policy. Please see the Terms and Conditions page for our full Warranty Policy.
Returns	Xtracycle Return Policy

The Xtracycle warranty covers each steel made frame and fork of the bicycle or e-bike against defects in manufacturing and materials for the lifetime of the bike for the original owner for personal use.

Aluminum frames and suspension forks are covered for five (5) years against defects in manufacturing and materials for the original owner for personal use.

Commercial use warranty is valid for one (1) year for the original owner for commercial use only, regardless of frame/fork material. Please see the Terms and Conditions page for our full Warranty Policy. Please see the Terms and Conditions page for our full Warranty Policy.
